BS ISO 4156-2:2005 (R2015)
Superseded , Reaffirmed Standard
Historical

BS ISO 4156-2:2005 (R2015)

Straight cylindrical involute splines. Metric module, side fit Dimensions
Most recent standard

Summary

Shape;Fillets (shape);Fits;Machining tolerances;Basic racks;SI system (metric);Cylindrical shape;Design;Angular tolerances;Locking and locating devices;Dimensions;Dimensional tolerances;Form tolerances;Involute splines;Splines;Straight

Technical characteristics

Publisher British Standards Institution (BSI)
Publication Date 01/19/2006
Confirmation Date 08/01/2015
Cancellation Date 02/09/2021
Page Count 198
Themes Straight
EAN ---
ISBN ---
Weight (in grams) ---
