DIN 4003-86:2017-03

This standard applies in conjunction with DIN 4003-1 and DIN 4000-86 and specifies the 3D-Modelling for drills and counter sinking tools for indexable cutting edges. In pictures taken from DIN 4000-86 the code letter of the property carries and underscore according to DIN 4003-1 and the symbol corresponding to ISO 13399. The level of detail of the 3D-models corresponds to the generic dimensional form. Details and features used in the process chain for NC-programming or simulation are not relevant and are omitted.
