DIN 644:2015-12

Linear motion rolling bearings - Flat cage rail guide - Dimensions and tolerances
Most recent standard

Summary

This document specifies mounting and fitting dimensions of Flat cage modular guide. These Linear rolling guide unit consists of two flat bars with the same or complementary shaped cross-section and one or more flat cages with rolling elements. The execution of this flat cages is independent of the connection dimensions and is left to the manufacturer.

Notes

Prévu pour remplacer DIN 644 (1997-10).

Technical characteristics

Publisher Deutsche Institut für Normung e.V. (DIN)
Publication Date 12/01/2015
Cancellation Date 12/01/2016
Page Count 14
EAN ---
ISBN ---
Weight (in grams) ---
