DIN 85005-1:1998-02
Superseded Standard
Historical

DIN 85005-1:1998-02

Ships and marine technology - Graphical symbols for technical documentation - Part 1: General instructions
Most recent standard

Summary

The document lays down shape and meaning of graphical symbols for technical documentation, scheme-drawings and plans such as general sketches and similar abstract descriptions for seagoing vessels, inland vessels, ships for the Federal German Navy and other authorities as well as for fixed and mobile marine structures. The graphical symbols are in accordance with the rules of DIN ISO 3461-2.

Notes

À remplacer par DIN 85005-1 (2016-03).

Technical characteristics

Publisher Deutsche Institut für Normung e.V. (DIN)
Publication Date 02/01/1998
Cancellation Date 05/01/2017
Page Count 8
EAN ---
ISBN ---
Weight (in grams) ---
