DIN ISO 3320:2015-02
Superseded Draft standard
Historical

DIN ISO 3320:2015-02

Fluid power systems and components - Cylinder bores and piston rod diameters and area ratios - Metric series (ISO 3320:2013)
Most recent standard

Summary

This document establishes a metric series of cylinder bore and piston rod diameters for hydraulic and pneumatic cylinders, and specifies for each pair of diameters a corresponding standard ratio between the useful areas.

Notes

Prévu pour remplacer DIN ISO 3320 (2001-08), DIN ISO 7181 (2001-08).

Technical characteristics

Publisher Deutsche Institut für Normung e.V. (DIN)
Publication Date 02/01/2015
Cancellation Date 01/01/2016
Page Count 8
EAN ---
ISBN ---
Weight (in grams) ---
