DIN ISO 8404:2005-09
Superseded Standard
Historical

DIN ISO 8404:2005-09

Tools for moulding - Angle pins (ISO 8404:2003)
Most recent standard

Summary

This International Standard specifies the basic dimensions, in millimetres, of headed angle pins (type A) and of straight angle pins (type B) intended for use in diescast dies and tools for moulding (an example of application is given in Figure 1). It also specifies the material hardness and designation of the angle pins (type A and B).

Notes

À remplacer par DIN ISO 8404 (2014-03).

Technical characteristics

Publisher Deutsche Institut für Normung e.V. (DIN)
Publication Date 09/01/2005
Cancellation Date 12/01/2014
Page Count 6
EAN ---
ISBN ---
Weight (in grams) ---
