IEC 60679-3:2012
IEC 60679-3:2012 Quartz crystal controlled oscillators of assessed quality - Part 3: Standard outlines and lead connections
Preview
Summary
IEC 60679-3:2012 specifies the outline dimensions and lead connections for quartz crystal controlled oscillators with lead enclosures. This edition includes the following significant technical changes with respect to the previous edition:
- CO 01, CO 07, CO 10, CO 17 and CO 18 were deleted;
- The current pin layout of CO 06 was deleted. And new pin layout of CO 06 was added as CO 40;
- New layout of CO 15 was added as CO 41;
- Two new enclosures, CO 42 and CO 43 were added. Therefore revised edition includes 15 types of enclosures as in Table 1 of Clause 5.
- CO 01, CO 07, CO 10, CO 17 and CO 18 were deleted;
- The current pin layout of CO 06 was deleted. And new pin layout of CO 06 was added as CO 40;
- New layout of CO 15 was added as CO 41;
- Two new enclosures, CO 42 and CO 43 were added. Therefore revised edition includes 15 types of enclosures as in Table 1 of Clause 5.
Technical characteristics
| Publisher | International Electrotechnical Commission (IEC) |
| Publication Date | 12/14/2012 |
| Edition | 3.0 |
| Page Count | 49 |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
