IEC 81714-2:2006
Active Standard
Most Recent

IEC 81714-2:2006

IEC 81714-2:2006 Design of graphical symbols for use in the technical documentation of products - Part 2: Specification for graphical symbols in a computer sensible form, including graphical symbols for a reference library, and requirements for their interchange

Summary

IEC 81714-2:2006 Specifies requirements for graphical symbols to be included in a reference symbol library in a computer sensible form, and requirements for their interchange among computer aided tools. The reference symbol library may be used as a basis for the design and editing of documents, and for the interchange of documents and graphical symbol libraries among computer-aided tools.

Technical characteristics

Publisher International Electrotechnical Commission (IEC)
Publication Date 06/13/2006
Edition 2.0
Page Count 169
EAN ---
ISBN ---
Weight (in grams) ---
No products.

Previous versions
