NBN ISO 16889:2022

This document describes the following:
— a multi-pass filtration performance test with continuous contaminant injection for hydraulic fluid
power filter elements;
NOTE 1 For the background interlaboratory study used to verify the test methodology, see Annex D.
— a procedure for determining the contaminant capacity, particulate removal and differential pressure
characteristics;
— a test currently applicable to hydraulic fluid power filter elements that exhibit an average filtration
ratio greater than or equal to 75 for particle sizes = 25 µm(c), and a final reservoir gravimetric level
of less than 200 mg/L;
NOTE 2 It is necessary to determine by validation the range of flow rates and the lower particle size limit that
can be used in test facilities.
— a test using ISO medium test dust (ISO MTD) contaminant and a test fluid in accordance with
Annex A.
This document is intended to provide a test procedure that yields reproducible test data for appraising
the filtration performance of a hydraulic fluid power filter element without influence of electrostatic
charge.
This document applies to three test conditions:
— test condition 1, with a base upstream gravimetric level of 3 mg/L;
— test condition 2, with a base upstream gravimetric level of 10 mg/L;
— test condition 3, with a base upstream gravimetric level of 15 mg/L.
