SAE AIR 1529A:2013-01-02
Superseded , Reaffirmed Standard
Historical

SAE AIR 1529A:2013-01-02

Flexure Testing of Hydraulic Tubing Joints and Fittings by Planar Resonant Vibration (Free-Free Beam)

Summary

This Aerospace Information Report (AIR) establishes flexure test procedures to determine and classify the fatigue strengths of reconnectable or permanent hydraulic tube joints.
The procedure is intended for conducting flexure tests of fittings and joints for hydraulic tubing materials such as AMS 5561 steel, AMS 4944 titanium and MIL-T-7081 aluminum alloy, mounted as free-free resonant beams.
Of particular advantage are the inherent simplicity of test setup, minimum restraint from a test fixture, low power requirements, short test duration, and ease of varying stress level.

Notes

Approuvée 2013-01-02, 2013-01-00, 2007-08-00, 2001-12-00, 1994-04-00.

Technical characteristics

Publisher SAE International
Publication Date 01/02/2013
Confirmation Date 01/02/2013
Page Count 13
Themes Aerospace
EAN ---
ISBN ---
Weight (in grams) ---
