SAE ARP 1234D:2021-08-26

Static Axial O-Ring Seal Applications Without Anti-Extrusion Devices for Engine and Engine Control Systems
Most recent standard

Summary

This document establishes standard gland design criteria and dimensions for static axial O-ring seal applications without anti-extrusion devices specifically for engines and engine control systems operating at a maximum pressure of 1500 psi (10345 kPa).
NOTE: The criteria herein are similar, but not identical, to those in AS4716 and the legacy standard MIL-G-5514.

Technical characteristics

Publisher SAE International
Publication Date 08/26/2021
Page Count 25
EAN ---
ISBN ---
Weight (in grams) ---
