SAE AS 3172A:2018-11-21
Superseded , Reaffirmed Standard
Historical

SAE AS 3172A:2018-11-21

BOLT, MACHINE - DOUBLE HEX EXTENDED WASHER HEAD, CLOSE TOLERANCE SHANK, AMS5643 (UNS S17400), 140 KSI, .5000-20, UNJF-3A
Most recent standard

Summary

REVISE THREAD SPECIFICATION TO AS8879. REVISE LIGHTENING HOLE CONFIGURATION (ADD SECTION VIEW) TO ALLOW OPTIONAL SHAPE AT BOTTOM OF HOLE, DELETE .015 MAX RADIUS AT BASE OF WRENCH PAD, UPDATE FPI REQUIREMENTS, ADD SURFACE FINISH REQUIREMENTS TO BOLT HEAD, ADD AS3062 FOR THREAD RUNOUT, ADD MIN. BEARING DIA, DELETE METRIC DIMENSIONS, UPDATE ANSI Y14.5-1973 TO ANSI Y14.5M- 1982, GENERAL EDITORIAL UPDATE, REFERENCES UDATED AND FIGURE 1 REDRAWN.

Technical characteristics

Publisher SAE International
Publication Date 10/04/2013
Confirmation Date 11/21/2018
Page Count 3
Themes Aerospace
EAN ---
ISBN ---
Weight (in grams) ---
