SAE J 1730:2012-03-15
ABS Exciter Ring Location Standardization
Preview
Summary
This SAE Recommended Practice establishes the Antilock Brake System [ABS] sensor interface and envelope dimensions for standardizing the location of the ABS rings mounted on the inner end of spoke wheels, hubs and hub-rotor assemblies on the following axle designations.
- a FF
- b FL
- c FC
- d FH
- e L
- f R
- g U
- h W
- j N
- k P
Technical characteristics
| Publisher | SAE International |
| Publication Date | 03/15/2012 |
| Page Count | 8 |
| Themes | Commercial Vehicle |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
Replaces
Previous versions
