DIN 3966-3:2012-07
Withdrawn Draft standard
Most Recent

DIN 3966-3:2012-07

Information on Gear Teeth in Drawings - Part 3: Information on worm and worm wheels
Most recent standard

Summary

This standard specifies minimum information on technical drawings of worms and worm wheels among common specifications on material, heat treatment and hardness. If required, additional specifications, such as manufacturing process or special testing and acceptance procedures, can be added. For representation of gears in technical drawings see DIN ISO 2203. Symbols, terms and definitions are in accordance with DIN 3975, DIN 3998 Part 4 and DIN 3999.

Notes

Prévu pour remplacer DIN 3966-3 (1980-11).

Technical characteristics

Publisher Deutsche Institut für Normung e.V. (DIN)
Publication Date 07/01/2012
Cancellation Date 09/01/2015
Page Count 14
EAN ---
ISBN ---
Weight (in grams) ---
